Number of armature slots in DC machine

For A 5kw Dc Motor The Number Of Slots Per Pole Should Bet

Brushless DC Motors or BLDC Motors have become a significant contributor of the modern drive technology. Their rapid gain in popularity has seen an increasing range of applications in the fields of Consumer Appliances, Automotive Industry, Industrial Automation, Chemical and Medical, Aerospace and Instrumentation. (ii)number of poles per pole arc should be an integer (+ 5 6;. (c) Lap Winding: In case of lap winding the number of slots should be (i)a multiple of pair of poles and (ii)slots per pole arc is an integer (+ 5 6. Number of Coils and Turns per Coil: The minimum number coils is given by C k g l L:EP/15. A dc motor develops a torque of 50Nm while rotating at 600rpm power developed by it is a four pole lap wound DC machine ha 48 slots on the armature with 8 conductors per slot the machine is driven at 1000 revolutions per minute and the useful flux per pole is 30mWb. DC Motor: motor that runs on direct current (DC) electricity. Principle of operation of DC Motor: When current carrying conductor is placed in a magnetic field it experience a force. Construction of DC Motor: 4. Construction of DC Motor: 5. Function of each part of DC Motor: Yoke:. It is outer cover of dc motor also called as frame.

Motor

In order to decide what number of slots (more or less) is to be used, the following merits and demerits are considered.

For

1. As the number of slots increases, cost of punching the slot increases, number of coils increases and hence the cost of the machine increases.

For a 5kw dc motor the number of slots per pole should be paid

2. As the number of slots increases, slot pitch λs = (slot width bs tooth width bt) = πD/ number of slots S

decreases and hence the tooth width reduces. This makes the tooth mechanically weak, increases the flux density in the tooth and the core loss in the tooth. Therefore efficiency of the machine decreases.

If the slots are less in number, then the cost of punching & number of coils decreases, slot pitch increases, tooth becomes mechanically strong and efficiency increases, quantity of insulation in the slot increases, heat dissipation reduces, temperature increases and hence the efficiency decreases.

Pole

It is clear that not much advantage is gained by the use of either too a less or more number of slots.

As a preliminary value, the number of slots can be selected by considering the slot pitch. The slot pitch can assumed to be between (2.5 and 3.5) cm. (This range is applicable to only to medium capacity machines and it can be more or less for other capacity machines).

For A 5kw Dc Motor The Number Of Slots Per Pole Should Be Paid

The selection of the number of slots must also be based on the type of winding used, quality of commutation, flux pulsation etc.

When the number of slot per pole is a whole number, the number slots embraced by each pole will be the same for all positions of armature. However, the number teeth per pole will not be same.

For A 5kw Dc Motor The Number Of Slots Per Pole Should Be

In order to decide what number of slots (more or less) is to be used, the following merits and demerits are considered.

1. As the number of slots increases, cost of punching the slot increases, number of coils increases and hence the cost of the machine increases.

2. As the number of slots increases, slot pitch λs = (slot width bs tooth width bt) = πD/ number of slots S

decreases and hence the tooth width reduces. This makes the tooth mechanically weak, increases the flux density in the tooth and the core loss in the tooth. Therefore efficiency of the machine decreases.

If the slots are less in number, then the cost of punching & number of coils decreases, slot pitch increases, tooth becomes mechanically strong and efficiency increases, quantity of insulation in the slot increases, heat dissipation reduces, temperature increases and hence the efficiency decreases.

It is clear that not much advantage is gained by the use of either too a less or more number of slots.

As a preliminary value, the number of slots can be selected by considering the slot pitch. The slot pitch can assumed to be between (2.5 and 3.5) cm. (This range is applicable to only to medium capacity machines and it can be more or less for other capacity machines).

For A 5kw Dc Motor The Number Of Slots Per Pole Should Be Paid

The selection of the number of slots must also be based on the type of winding used, quality of commutation, flux pulsation etc.

When the number of slot per pole is a whole number, the number slots embraced by each pole will be the same for all positions of armature. However, the number teeth per pole will not be same.

This causes a variation in reluctance of the air gap and the flux in the air gap will pulsate. Pulsations of the flux in the air gap produce iron losses in the pole shoe and give rise to magnetic noises. On the other hand, when the slots per pole is equal to a whole number plus half the reluctance of the flux path per pole pair remains constant for all positions of the armature, and there will be no pulsations or oscillations of the flux in the air gap.

To avoid pulsations and oscillations of the flux in the air gap, the number of slots per pole should be a whole number plus half. When this is not possible or advisable for other reasons, the number of slots per pole arc should an integer.

Number of teeth/pole shoe = 5 and flux passes through 5 teeth.

For A 5kw Dc Motor The Number Of Slots Per Pole Should Be Replaced

The reluctance of the air gap is inversely proportional to the area corresponding to 5 teeth.
